The KPC-176B Side Outlet Tee is a cast-iron pipe clamp fitting for 48.3 mm OD, 1-1/2" Sch. 40 pipe. It joins three horizontal pipes to a vertical column at 90° in one four-way fitting, using internal hex screws to lock the pipe without welding so structural pipework can be assembled, adjusted, and serviced on site.
Why It Matters
The black finish helps visible pipe structures sit quieter in scenic, retail, and event environments while preserving the corrosion-resistant hot-dip galvanized base treatment.
Key Features
Four-way configuration connects three horizontal pipes and one vertical column at 90°.
ASTM A197 cast iron body supports demanding modular pipe structures.
Double-layer hot-dip galvanization helps protect the fitting in indoor and outdoor service.
Internal hex screws secure the pipe without welding, keeping the assembly relocatable.
Applications
Use for free-standing barrel grids, exhibition booths, retail displays, guardrail corner posts, display rigs, and modular column intersections.
Compatibility
Fits 48.3 mm OD, 1-1/2" Sch. 40 pipe; related sister fittings cover the alternate KUPO pipe clamp diameter.
Frequently Asked Questions
Does this fitting need welding?
No. It uses internal hex screws, so it can be installed and repositioned without welding.
When is this better than separate tees?
Use it when three horizontal branches need to meet the same vertical post at the same elevation.
What pipe size does this version fit?
This version is specified for 48.3 mm OD, 1-1/2" Sch. 40 pipe.
