Overview

The ZLC-200RGBA is a 200 W KUPO LED Cyclorama fixture with asymmetric optics for lighting backdrops, skydrops, and large evenly illuminated surfaces. This RGBA color-mixing version uses 72 x 3 W RGBA LEDs, delivering the wide V90° / H120° coverage needed for smooth cyc washes from a short throw distance.

Why It Matters

The 200 W RGBA model is the larger color-mixing choice when a bigger cyc or brighter backdrop needs saturated color and amber-assisted mixes. It gives designers more output while keeping the same asymmetric distribution logic.

Key Features

• Asymmetric optics create a wide V90° / H120° distribution for even vertical and horizontal backdrop coverage.
• 72 x 3 W RGBA LEDs gives this model its rgba output character.
• DMX-512 control through 3pin or 5-pin XLR supports addressing through the on-board LCD and push-button navigation.
• Power and signal feed-through support daisy-chain rigging across repeated cyclorama fixtures.
• Aluminum alloy housing, eye ring, lock-washer bracket hardware, and rubber footpad support both rigged and floor-standing use.

Additional Technical Notes

• Control Mode: DMX-512, stand-alone, strobe, 0-100 % dimming, master/slave

Applications

Used for larger theatre backdrops, event stages, touring scenic walls, retail display surfaces, galleries, and color-changing architectural washes that need the 200 W output class.

Compatibility

Part of the KUPO LED Cyclorama family covering 150 W and 200 W RGBA, warm white, tunable white, and UV variants. Protection classification is IP20.
