Product Description
Overview
The KUPO KCP-804-XP Pipe-to-Pipe Coupler is a polished 1000 mm 90° cross assembly for connecting 48 to 51 mm tubes with 50 mm center-to-center spacing. Two heavy-duty couplers are welded to an aluminum spacer, creating a 200 kg Working Load Limit component for long modular pipe-grid extensions.
Why It Matters
The 1000 mm cross version gives a long fixed 90° relationship for pipe-grid intersections, bracing, and crossover points. It is cleaner than stacking loose couplers when the perpendicular tube needs to land square and stay there.
Key Features
- 90 °Cross configuration creates a long fixed 90° pipe crossover
- 200 kg Working Load Limit supports planned modular pipe-grid and rigging extensions
- 1000 mm assembly length with 50 mm center-to-center tube spacing gives repeatable geometry
- 48 to 51 mm tube fit matches standard 2" stage pipe and truss tube
- Polished finish suits exposed polished hardware and shop inventory
Applications
Use it for long 90° pipe crossovers, diagonal bracing layouts, truss-grid intersections, exhibition frames, and fixture positions that need a perpendicular pipe locked to an existing run.
Compatibility
Fits 48 to 51 mm tube. Sister variants cover parallel and 90° cross configurations in 250 mm, 500 mm, and 1000 mm lengths, with polished and black finishes.
Frequently Asked Questions
Why choose the 1000 mm cross version?
Choose it when the perpendicular pipe needs a longer fixed relationship to the parent tube. Shorter cross versions are cleaner for compact crossover points.
Does the center spacing change on the 1000 mm model?
No. The specification lists 50 mm center-to-center spacing. The 1000 mm figure is the assembly length.
What tube size does it fit?
It is specified for 48 to 51 mm tube, which covers common 2" stage pipe and truss tube. Check actual outside diameter before ordering.
