The KCP-883 Mighty Handcuff Eye Ring Opening Coupler combines a fast-opening handcuff clamp with a 30 mm integrated pickup eye. Built from 6061-T6 high tensile aluminum extrusion for 48-60 mm tube, it gives riggers a compact way to add a shackle, hook, safety cable, or pickup point without building up extra loose adapters.
Why It Matters
For main chord pickups and safety points, the eye needs to feel like part of the clamp, not an afterthought. This wider handcuff body gives the attachment point a stable base on the tube.
Key Features
Integrated 30 mm eye ring creates a direct attachment point for shackles, hooks, safety cables, or pickup details.
40 mm handcuff body closes quickly around 48-60 mm tube and keeps the eye aligned with the clamp position.
200 kg Working Load Limit (WLL) suits stronger pickup work on main truss chord runs.
Applications
A practical pickup clamp for motor chain details, safety cable runs, truss chords, hanging fixtures, and rental rigs where the eye point needs to be fast to place and easy to inspect.
Compatibility
Fits 48-60 mm tube and provides a 30 mm eye ring; use with compatible shackles, hooks, and rated rigging hardware.
Frequently Asked Questions
Can the eye take a shackle or safety cable?
Yes, the 30 mm eye is intended for compatible shackles, hooks, and steel safety cables, provided the complete assembly stays within the rated load.
When is the wider eye ring version worth using?
Use the wider version when the pickup point benefits from a broader 40 mm clamp body on the tube, especially on main chord runs.
Does the handcuff still open fully with the eye attached?
Yes. The eye is integrated into the fitting while the clamp still uses the same open-around-the-tube handcuff action.
