Overview

The KUPO KCWPVC1x80 Power Cable is a flexible single-core IV feeder for portable power distribution and fixed installation work. Its fine-stranded copper conductor helps the cable stay manageable during repeated handling, while PVC insulation and a PVC outer sheath give the jacket a clean strip, smooth gland fit, and dependable field durability.

Why It Matters

This 80 mm² size is designed for substantial feeder runs where higher current capacity is needed before moving to the largest 100 mm² cable in the family. The 600 V rating and 105 °C temperature rating make this size useful for professional power builds where the cable has to carry current confidently but still coil, route, and terminate without fighting the crew.

Key Features

• 80 mm² single-core IV copper conductor for feeder and single-pole assemblies
• Approximate ampacity of 320 A with maximum resistance of 0.24 Ohm/km at 20 °C
• PVC insulation and PVC outer sheath with 2.30 mm jacket thickness
• 18.1 mm outer diameter for planning glands, rings, and crossover protection
• Rated 600 V with a 105 °C temperature rating

Applications

KCWPVC1x80 is suited to single-pole feeder runs, cam-style connector assemblies, portable power distribution, fixed installation feeders, and event or industrial environments where a flexible single-core power cable is required.

Compatibility

Use KCWPVC1x80 with properly rated connectors, cable glands, rubber rings, color-coded jacket systems, and cable crossover protection sized for a 18.1 mm outer diameter and the required current load.
