Overview
The KUPO KCWPVC4x14 Power Cable is a multi-core CSA construction for power distribution jobs that need several conductors protected inside one jacket. Fine-stranded copper keeps the cable workable, while PVC insulation and a durable PVC outer sheath help the cable seat cleanly into glands and stay consistent through repeated handling.
Why It Matters
The 4-core 14 mm² layout adds another conductor while keeping the heavier conductor size for distribution runs that need more complete wiring in one jacket. Multi-core construction keeps related conductors together, which can make drop-box feeds, distribution runs, and fixed routes cleaner than building the same path from separate single-core lines.
Key Features
- 14 mm² x 4 C multi-core CSA construction
- Approximate ampacity of 63 A with maximum resistance of 1.43 Ohm/km at 20 °C
- PVC insulation and PVC outer sheath with 1.20 mm jacket thickness
- 22.0 mm outer diameter for routing and gland planning
- Rated 600 V with a 60 °C temperature rating
Applications
KCWPVC4x14 is suited to distribution feeders, drop boxes, fixed runs, temporary venue builds, and industrial or event cable systems where a jacketed, color-coded multi-conductor power cable is preferred.
Compatibility
Use KCWPVC4x14 with properly rated distribution equipment, connectors, cable glands, strain relief, and protection sized for a 22.0 mm outer diameter and a 14 mm² x 4 C conductor layout.
