KPC-058B - Pipe Clamp 4 Way Cross (Black)

Name: KPC-058B - Pipe Clamp 4 Way Cross (Black)
Brand: KUPO Stage

1 2

Product Description

Overview

The KPC-058B Pipe Clamp 4 Way Cross is a bolt-on malleable iron fitting for 42.4 mm OD, 1-1/4" Sch. 40 pipe. It joins four pipes meeting at a single right-angle intersection, using stainless steel hex screws to lock the pipe without welding so frame, rail, and display structures can be assembled and revised on site.

Why It Matters

The black finish helps visible pipe frames sit quieter in scenic, retail, and event environments. Functionally, the fitting still carries the corrosion-resistant pipe clamp construction and bolt-on serviceability crews expect.

Key Features

Four-way right-angle geometry organizes four pipe directions at one intersection.
Malleable iron casting per ASTM A197 provides a durable body for tubular structures.
ASTM A153 hot dip galvanized treatment plus zinc plating supports corrosion resistance for demanding environments.
Stainless steel hex screws lock the pipe firmly without welding, helping crews build and rework faster.

Applications

Built for pipe grids, cube frames, retail displays, scenic wall systems, guardrail intersections, exhibition frames, and structural layouts where four members meet cleanly.

Compatibility

Fits 42.4 mm OD, 1-1/4" Sch. 40 pipe; related sister fittings cover the alternate KUPO pipe clamp diameter.

Frequently Asked Questions

Does this fitting require welding?

No. It locks the pipe with stainless steel hex screws, so the structure remains bolt-on and easier to reconfigure.

When is a four-way cross useful?

Use it when four pipe directions meet at one right-angle intersection and you want that junction handled by one fitting.

What pipe size does this version fit?

This version fits 42.4 mm OD, 1-1/4" Sch. 40 pipe, commonly used as 1-1/4" nominal Schedule 40 pipe.
