The KPC-168B Pipe Clamp 90? Corner Swivel is a 100-series bolt-on fitting for 48.3 mm OD, 1-1/2" Sch. 40 pipe. It forms a right-angle corner with a swiveling joint for braced corners, using stainless steel hex screws to lock the pipe without welding so smaller-format rail, display, and frame structures can be assembled and reworked on site.
Why It Matters
The black finish helps visible pipe structures sit quieter in scenic, retail, and event environments while keeping the same no-weld pipe clamp workflow.
Key Features
Right-angle corner layout with swivel adjustment supports braced frame corners.
Malleable iron casting per ASTM A197 provides a durable body for modular tubular structures.
ASTM A153 hot dip galvanized treatment plus zinc plating supports corrosion resistance in demanding environments.
Stainless steel hex screws lock the pipe without welding, helping crews assemble and revise frames cleanly.
Applications
Use for braced corners, angled frame returns, scenic structures, guardrails, retail pipe frames, and display builds with square corners plus diagonal support.
Compatibility
Fits 48.3 mm OD, 1-1/2" Sch. 40 pipe; related sister fittings cover the alternate KUPO pipe clamp diameter.
Frequently Asked Questions
Does this fitting need welding?
No. It locks the pipe with stainless steel hex screws, keeping the structure bolt-on and easier to revise.
Why use a corner swivel instead of a fixed corner?
Use it when the corner needs a right-angle relationship but one connected member must still swivel for bracing or site geometry.
What pipe size does this version fit?
This 100-series version fits 48.3 mm OD, 1-1/2" Sch. 40 pipe, also described as 1-1/2" nominal Schedule 40 pipe.
