The KPC-A1430 C Short Tee Swivel is an A535 aluminum-magnesium alloy slip-on pipe clamp for 42.40 mm (1.66") outside diameter tube. It adds a compact tee with a swivel branch so the perpendicular tube can angle off-axis from the main run, using 3/8" galvanized steel recessed grub screws with reverse knurled cup points for a no-weld structure that installs with a standard hex key.
Why It Matters
A fixed tee can make a brace fight the frame when the angle is not square. This short tee swivel gives the branch freedom while keeping the fitting compact.
Key Features
Swivel branch allows the perpendicular tube to leave the main run at an adjustable angle.
A535 aluminum-magnesium alloy keeps the fitting lightweight and corrosion resistant for outdoor or harsh environments.
3/8" galvanized steel recessed grub screws with reverse knurled cup points hold the tube securely.
Standard hex-key installation avoids welding, specialist labor, and permanent fabrication.
Additional Technical Notes
Set Screws: 3/8" galvanized steel recessed grub screw with reverse knurled cup point
Applications
Use for diagonal branches, compact display frames, angled supports, scenic structures, retail pipework, and layouts where the branch needs both short spacing and angle adjustment.
Compatibility
Fits 42.40 mm (1.66") outside diameter tube for Schedule 40 nominal pipe. The related KPC-A1230 C version fits 48.30 mm tube.
Frequently Asked Questions
Is this part of the aluminum-magnesium clamp family?
Yes. It is an A535 aluminum-magnesium alloy slip-on fitting for lightweight, corrosion-resistant pipe structures.
Why use the swivel version instead of a fixed tee?
Use the swivel version when the branch tube needs to leave the main run at an angle rather than a fixed square position.
Which tube size does this version fit?
This A1400-series version fits 42.40 mm outside diameter tube. The A1200-series sister version fits 48.30 mm tube.
