The KPC-A1462 Sleeve Joint is an A535 aluminum-magnesium alloy slip-on pipe clamp for 42.40 mm (1.66") outside diameter tube. It joins two tube lengths end-to-end into one continuous run, using 3/8" galvanized steel recessed grub screws with reverse knurled cup points for a no-weld structure that installs with a standard hex key.
Why It Matters
A straight run should stay straight at the joint. This sleeve extends tube work without welding and keeps the connection visually clean.
Key Features
Inline sleeve joins two tube lengths end-to-end without offset.
A535 aluminum-magnesium alloy keeps the fitting lightweight and corrosion resistant for outdoor or harsh environments.
3/8" galvanized steel recessed grub screws with reverse knurled cup points hold the tube securely.
Standard hex-key installation avoids welding, specialist labor, and permanent fabrication.
Additional Technical Notes
Set Screws: 3/8" galvanized steel recessed grub screw with reverse knurled cup point
Applications
Use for extending display rails, long guardrails, retail pipe runs, scenic frames, outdoor structures, and any straight tube span that needs a clean serviceable joint.
Compatibility
Fits 42.40 mm (1.66") outside diameter tube for Schedule 40 nominal pipe. The related KPC-A1262 version fits 48.30 mm tube.
Frequently Asked Questions
Is this part of the aluminum-magnesium clamp family?
Yes. It is an A535 aluminum-magnesium alloy slip-on fitting for lightweight, corrosion-resistant pipe structures.
Does this fitting create a branch?
No. It joins two tube ends inline to extend a straight run.
Which tube size does this version fit?
This A1400-series version fits 42.40 mm outside diameter tube. The A1200-series sister version fits 48.30 mm tube.
