Overview
The ZLC-150RGBA is a 150 W KUPO LED Cyclorama fixture with asymmetric optics for lighting backdrops, skydrops, and large evenly illuminated surfaces. This RGBA color-mixing version uses 48 x 3 W RGBA LEDs, delivering the wide V90° / H120° coverage needed for smooth cyc washes from a short throw distance.
Why It Matters
RGBA is the most flexible 150 W color member because amber expands the palette beyond pure RGB saturation. It can build rich colors, softer pastels, and warmer stage looks from a compact cyc fixture.
Key Features
- Asymmetric optics create a wide V90° / H120° distribution for even vertical and horizontal backdrop coverage.
- 48 x 3 W RGBA LEDs gives this model its rgba output character.
- DMX-512 control through 3pin or 5-pin XLR supports addressing through the on-board LCD and push-button navigation.
- Power and signal feed-through support daisy-chain rigging across repeated cyclorama fixtures.
- Aluminum alloy housing, eye ring, lock-washer bracket hardware, and rubber footpad support both rigged and floor-standing use.
Additional Technical Notes
- Control Mode: DMX-512, stand-alone, strobe, 0-100 % dimming, master/slave
Applications
Used for theatre backdrops, skydrops, event stages, gallery washes, retail display walls, and color-changing cyc effects where a 150 W RGBA fixture is the right size.
Compatibility
Part of the KUPO LED Cyclorama family covering 150 W and 200 W RGBA, warm white, tunable white, and UV variants. Protection classification is IP20.
