Overview
The ZLC-150UV is a 150 W KUPO LED Cyclorama fixture with asymmetric optics for lighting backdrops, skydrops, and large evenly illuminated surfaces. This 365 nm UV version uses 48 x 3 W 365 nm UV LEDs, delivering the wide V90° / H120° coverage needed for smooth cyc washes from a short throw distance.
Why It Matters
The UV version is not a general wash color. It is for blacklight activation on scenic paint, costumes, props, and themed surfaces where 365 nm ultraviolet output is part of the design.
Key Features
- Asymmetric optics create a wide V90° / H120° distribution for even vertical and horizontal backdrop coverage.
- 48 x 3 W 365 nm UV LEDs gives this model its uv output character.
- DMX-512 control through 3pin or 5-pin XLR supports addressing through the on-board LCD and push-button navigation.
- Power and signal feed-through support daisy-chain rigging across repeated cyclorama fixtures.
- Aluminum alloy housing, eye ring, lock-washer bracket hardware, and rubber footpad support both rigged and floor-standing use.
Additional Technical Notes
- Control Mode: DMX-512, stand-alone, strobe, 0-100 % dimming, master/slave
Applications
Used for theme-park dark rides, immersive theatre, UV scenic effects, blacklight backdrops, event environments, and installations using fluorescent materials.
Compatibility
Part of the KUPO LED Cyclorama family covering 150 W and 200 W RGBA, warm white, tunable white, and UV variants. Protection classification is IP20.
