Overview

The ZLC-150WW is a 150 W KUPO LED Cyclorama fixture with asymmetric optics for lighting backdrops, skydrops, and large evenly illuminated surfaces. This warm-white version uses 48 x 3 W Warm White LEDs (3200 K), delivering the wide V90° / H120° coverage needed for smooth cyc washes from a short throw distance.

Why It Matters

Warm white is the straightforward choice when the cyc needs a tungsten-temperature base wash. It keeps the backdrop even and familiar without adding color-mixing complexity.

Key Features

• Asymmetric optics create a wide V90° / H120° distribution for even vertical and horizontal backdrop coverage.
• 48 x 3 W Warm White LEDs (3200 K) gives this model its warm white output character.
• DMX-512 control through 3pin or 5-pin XLR supports addressing through the on-board LCD and push-button navigation.
• Power and signal feed-through support daisy-chain rigging across repeated cyclorama fixtures.
• Aluminum alloy housing, eye ring, lock-washer bracket hardware, and rubber footpad support both rigged and floor-standing use.

Additional Technical Notes

• Control Mode: DMX-512, stand-alone, strobe, 0-100 % dimming, master/slave

Applications

Used for theatre cycloramas, studio backdrops, warm architectural surfaces, event stages, and productions that need an even 3200 K backdrop wash.

Compatibility

Part of the KUPO LED Cyclorama family covering 150 W and 200 W RGBA, warm white, tunable white, and UV variants. Protection classification is IP20.
